BS 8414 Fire Resistance Test Equipment for External Cladding Systems

  • 1
  • 2

Brand Name : Delta

Model Number : GCF

Certification : ISO9001

Place of Origin : China Mainland

MOQ : 1 set BS 8414 Fire Resistance Test Equipment for External Cladding Systems

Price : USD1.0 / set BS 8414 Fire Resistance Test Equipment for External Cladding Systems

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100 sets / month

Delivery Time : Within 30 days after the order is confirmed

Packaging Details : BS 8414 Fire Resistance Test Equipment for External Cladding Systems is packed in one plywood case.

Name : BS 8414 Fire Resistance Test Equipment for External Cladding Systems

Reference Standard : BS 8414 Appendix C

Application : Test Fire Resistance Performance of External Wall

Function : Test Moldering of Insulation Material

Data Display : Temperature Values and Temperature Curves

Display : Digital Display

Type : Fire Resistance Testing Equipment

Language : English

Power Supply : 220V, 10A

Installation Space : Floor Standing Fume Hood

Dimension : 1220 * 750 * 1340mm

Weight : 39kg

Contact Now

BS 8414 Fire Resistance Test Equipment For External Cladding Systems

Brief Introduction:
The BS 8414 Fire Resistance Test Equipment For External Cladding System is mainly used for testing the fire resistance performance of external wall insulation systems in buildings.
BS 8414 Fire Resistance Test Equipment For External Cladding Systems is suitable for testing the smoldering characteristic of insulation materials in building external insulation systems.
This test method is Appendix C of BS 8414 "Fire performance of external cladding systems Test method for non-loadbearing external cladding systems", which is the smoldering characteristic test method.

Main Features:
1. Equipped with a programmable temperature controller, providing a standard temperature rise curve;
2. The testing time is 24 hours, and the temperature is displayed and controlled throughout the entire process;
3. Complies with the testing standards BS 8414 and GB/T29416-2012 Appendix C Test Methods for Fire Performance of Building External Wall Insulation Systems;
4. The testing software can display temperature values and temperature curves;
5. Provide furnace thermocouples and sample surface thermocouples;
6. If the center temperature of the sample is the same as the furnace temperature, it indicates that there is no tendency for smoldering of the sample within the test cycle and temperature range;
7. During the entire experimental process (24 hours), if the sample exhibits a test trajectory with self-heating characteristics, it is determined that the sample has a tendency to smolder.

Size and weight:
Size: 1220 * 750 * 1340mm
Weight: 39KG

Installation requirements:
Power requirements: 220V, 10A
Environmental temperature: 10 ° C to 35 ° C
Installation space: Floor-standing fume hood
